主要特點與功能 該系列設備充分滿足了大產量物料的濕法粉碎加工要求。該系列設備充分利用剪切粉碎原理,通過定轉子相互精密嚙合,轉子在超高線速度運轉下產生強烈剪切、撞擊、研磨和空穴作用,使物料達到顯著的粉碎效果,提高了物料的粉碎品質。該系列設備具有結構緊湊、能耗低和易維護等特點。
Primary traits and functions The series of equipment are fully satisfied with on-line super output wet pulverization processing requirements of the materials. The equipment makes full use of the principle of superfine grinding .And the structure with stator-rotor of shear pattern is designed to satisfy the superfine grinding.The material can be pulverized effectively to improve product quality by the synthetic action of high shearing, impacting, grinding and cavitation resulted from the super high linear velocity. In addition, the equipment has some other traits, such as compact conformation, low energy consumption and easy maintenance, etc.
應用范圍 主要應用于超大流量的谷物類物料的粉碎作用,對于皮渣類物料的進一步粉碎要求的效果尤為顯著。如:辣椒、番茄 皮渣、甜玉米、白蘭豆、大豆、菠蘿、木薯、紅薯、秸桿、海藻、水產品廢料等。
Application scope The series of equipment are primarily applicable to pulverization of corn with super mass flow, especially to the further pulverization of peel and dregs. Such as chili, tomato bran, jam, sweet corn, prynne bean, pineapple, cassava, sweet potato, straw, eaweed, fishskin, fishbone and other various peel and dregs, etc.
型號type | 功率power(kW) | 轉速speed(RPM) | 處理量output(kg/h) |
QDWⅠ3000-5 | 5.5 | 3000 | 100-500 |
QDWⅠ3000-7 | 7 | 3000 | 500-1500 |
QDWⅠ3000-11 | 11 | 3000 | 300-2000 |
QDWⅠ3000-15 | 15 | 3000 | 1000-3000 |
QDWⅠ3000-18 | 18 | 3000 | 1000-3000 |
QDWⅠ3000-22 | 22 | 3000 | 2000-4000 |
QDWⅠ3000-30 | 30 | 3000 | 2000-6000 |
QDWⅠ3000-37 | 37 | 3000 | 3000-8000 |
QDWⅠ3000-75 | 75 | 3000 | 5000-15000 |
QDWⅠ3000-132 | 132 | 3000 | 10000-30000 |
QDWⅠ6000-15 | 15 | 6000 | 800-2500 |
QDWⅠ6000-22 | 22 | 6000 | 1500-3000 |
QDWⅠ6000-37 | 37 | 6000 | 2500-6000 |
QDWⅡ3000-15 | 15 | 3000 | 800-2500 |
QDWⅡ3000-22 | 22 | 3000 | 1500-3000 |
QDWⅢ3000-22 | 22 | 3000 | 1000-2500 |
