功能說明：
適用范圍：適合易碎不易自動計量的物品，如：薯片、饃片、鍋巴、果凍、水餃、湯圓等的包裝。
Suitable for frangible goods and those goods which are hard on auto metering, such as potato chips, steam bread chips, crispy rice, fruit jelly, boiled dumpling, rice dumpling etc.
主要性能和特點：
Function and structure characteristics:
1.設計簡單、合理、性能穩定，噪音低，易維護，鏈斗式傳送。
2.人工計量投料包裝，鏈斗式投料方便投獎卡、獎品、或多種物料同時包裝，沒有物料時機器不會出空袋，損耗少，整套配置經濟實惠。
1.compact and ational structure, stable performance, low noise, easy maintainance bucket chain conveyor.
2.Feeding and packaging with manual metering, the bucket chain conveyer is convenient on feeding. The award card, award or several kinds of material can be packaged at the same time, no empty bags will be delivered when there is no material, less waste, complete set of the machine is economical and practical.
Complete set of this machine
1. ZV-420 principal machine
2.Bucket chain conveyor
3.Finished product conveyer
技術規格
| 機型type | ZV-420 |
| 耗氣量Air consumption | 2.5m3/min.6kg/cm2 |
| 包裝膜寬度Max film wiidth | 180-420mm |
| 制袋長度bag lenght | 80-300mm |
| 制袋寬度bag width | 80-200mm |
| 卷材外徑Max. external diameter of coiled material | Max.300mm |
| 包裝速度packing speed | 5-70bags/min |
| 薄膜厚度packing thickness | 0.04-0.08mm |
| 電源規格power | 220V.50/60Hz.2.4KVA |
| 外形尺寸Dimension | (L)1100x(W)925x(H)1620mm |
| 機器總重量total weight of the machine | 650kg |
